Fast Wheels FC04 Alloy Wheel (Metallic Black) — 17", 18", 19", 20"
Fast Wheel's stunning FC04 Alloy Wheel is an exceptionally stunning year-round choice for both the track and the streets! The FC04 is part of Fast Wheel's competition series. Featuring: lightweight construction, flow formed technology (making it 20% lighter) and finished in an alluring Metallic Black finish.
Fast Wheels crafts each wheel with high quality alloy and engineers all wheels for optimized fuel economy, improved acceleration and cornering. All wheels are tested to exceed JWL, VIA and SAE standards and CASS (salt spray) corrosion tested.
Click Here to view available fitments for your Mazda or by using the "Applications" tab!
- Details
- Specifications
- Applications
-
- Five (5) Y-spoke design
- Available in 17", 18", 19", 20" diameters
- Stunning Metallic Black Finish
- Lightweight, high-performance, single-piece alloy construction
- Made using Flow Forming technology, maximizing both strength and affordability
- Includes Centre Cap, in Satin Black with Chrome Outline Fast FC logo
- Optional: Exclusive Fast Wheels FC Red Center Cap
- Optional: High Type Center Caps, Red & Black Emblems, replacement Black Emblems
- Optional: Exclusive Fast Wheels FC Center Ring
- Certifications: JWL, VIA
-
- Style #: FC04
- Finish: Metallic Black
- Pitch Circle Diameter (PCD): 5×114.3mm
- Hub Bore Diameter: 72.6mm
- Lug Seat: 60° Conical
- All-Season Approved: Yes
Wheel Size Offset (mm) Weight (lbs./kg) Load Rating (lbs./kg) 17"×8.0" +45 16.6/7.5
1521/690 17"×8.0" +35 17.0/7.7 1521/690 18"×8.0" +40 18.8/8.5 1521/690 18"×8.0" +30 19.4/8.8 1521/690 18"×9.0" +40 19.0/8.6 1521/690 18"×9.0" +30 19.2/8.7 1521/690 19"×8.5" +45 20.8/9.4 1521/690 19"×8.5" +35 21.4/9.7 1521/690 19"×9.5" +45 20.0/9.1 1521/690 19"×9.5" +35 20.4/9.3 1521/690 20"×8.5" +45 23.4/10.6 1797/815 20"×8.5" +35 24.8/11.2 1797/815 20"×9.5" +45 23.4/10.6 1797/815 20"×9.5" +35 24.2/11.0 1797/815 -
Wheel Size
Offset17"×8.0",
+45mm17"×8.0",
+35mm18"×8.0",
+40mm18"×8.0",
+30mm18"×9.0",
+40mm18"×9.0",
+30mmCX-3
2016-2022 2016-2022 2016-2022 ❌ 2016-2022 ❌ CX-30
2020-2024 2020-2024 2020-2024
❌ ❌ ❌ CX-5 2013-2024 2013-2014 2013-2024 2013-2024 2013-2024 ❌ CX-50 2023-2024 2023-2024 2023-2024 2023-2024 2023-2024 ❌ CX-7 2007-2012 2007-2012 2007-2012 2007-2012 2007-2012 ❌ CX-9 ❌ ❌ 2007-2015
2007-2015
2007-2015
2007-2015
Mazda3 2004-2024 ❌ 2019-2024
❌ ❌ ❌ Mazda6 2009-2021 2009-2021 2009-2021 ❌ 2014-2017 ❌ RX-8 ❌ ❌ 2004-2011 2004-2011 2004-2011 2004-2011* Wheel Size
Offset19"×8.5",
+45mm19"×8.5",
+35mm19"×9.5",
+45mm19"×9.5",
+35mm20"×8.5",
+45mm20"×8.5",
+35mm20"×9.5",
+45mm20"×9.5",
+35mmCX-3
2016-2022 ❌ ❌ ❌ ❌ ❌ ❌ ❌ CX-30
2020-2024 2020-2024 2020-2024
❌ 2020-2024 ❌ ❌ ❌ CX-5 2013-2024 2013-2014 2013-2024 2013-2024 2013-2024 2013-2024 ❌ ❌ CX-50 2023-2024 2023-2024 2023-2024 2023-2024 2023-2024 2023-2024 ❌ ❌ CX-7 2007-2012 2007-2012 ❌ ❌ 2007-2012 2007-2012 ❌ ❌ CX-9 2007-2015
2007-2015
2007-2015
2007-2015
2007-2023
2007-2023
❌ 2016-2023 Mazda6 2009-2021 2014-2017 2014-2017 ❌ 2009-2021 2014-2017
2014-2017 ❌ RX-8 2004-2011
2004-2011 2004-2011 2004-2011* 2004-2011 2004-2011 2004-2011 2004-2011* *Fitment only on rear axle for Mazda RX-8 vehicles
Since there are several application combinations possible, we've highlighted the easiest sizes to fit your Mazda. All listed sizes for each vehicle are wheel manufacturer-recommended fitments based on factory vehicle suspension components, and no vehicle modifications should be necessary.
Should your vehicle have any modifications, then we can no longer guarantee fitment to your vehicle. If your Mazda is not listed, then this wheel does not have an appropriate size available for your vehicle.
Special Notes:
- Wheel does not accommodate OEM wheel nuts
- Not Included:
- Tire Valves
- Available: Chrome Tire Valves
- Hub-Centric Rings
- Available: Hub-Centric Rings
- Wheel Nuts
- Available: 6-Spline Wheel Nuts in Black or Chrome
- Please ensure you select the correct size of wheels for your vehicle
- If you choose to upsize or downsize, the corresponding tire size must also be changed
- If you are unsure of your sizing, please contact us and we'll be more than happy to help!
- Installation Option Available: Please contact us for further details
- Please review our Shipping Policies prior to purchase
- Be sure to also check out our collection of All Season Tires and Winter Tires to get you set for the roads!
About Fast Wheels
Fast Wheels is a proudly Canadian alloy wheel brand dedicated to covering a wide range of wheel styles and fitments for all types of passenger vehicles. Their team has over 30 years experience in wheels, and our products are a testament to our enthusiasm and wealth of industry knowledge.
Fast Wheels is committed to overseeing each step of a wheel’s existence. From the moment it’s conceived on the computer screen to its birth in the casting machine, each step of the manufacturing process is closely monitored. The wheel is seen through a series of certification tests right down to the finishing and packaging, making sure your wheels are constructed with the highest quality control standards in the industry.
