Fast Wheels FC04 Alloy Wheel (Titanium) — 17", 18", 19", 20"
Fast Wheel's stunning FC04 Alloy Wheel is an exceptionally stunning year-round choice for both the track and the streets! The FC04 is part of Fast Wheel's competition series. Featuring: lightweight construction, flow formed technology (making it 20% lighter) and finished in an alluring Titanium finish.
This wheel is priced individually.
Please ensure to select your desired quantity.
Fast Wheels crafts each wheel with high quality alloy and engineers all wheels for optimized fuel economy, improved acceleration and cornering. All wheels are tested to exceed JWL, VIA and SAE standards and CASS (salt spray) corrosion tested.
View available fitments for your Mazda using the "Applications" tab!
- Details
- Specifications
- Applications
-
- Five (5) Y-spoke design
- Available in 17", 18", 19", 20" diameters
- Stunning Titanium Finish
- Lightweight, high-performance, single-piece alloy construction
- Made using Flow Forming technology, maximizing both strength and affordability
- Includes Centre Cap, in Satin Black with Chrome Outline Fast FC logo
- Optional: Exclusive Fast Wheels FC Red Center Cap
- Optional: High Type Center Caps, Red & Black Emblems, replacement Black Emblems
- Optional: Exclusive Fast Wheels FC Center Ring
- Certifications: JWL, VIA
- Style #: FC04
- Finish: Titanium
- Wheel Diameter: 17", 18", 19", 20"
- Pitch Circle Diameter (PCD): 5×114.3mm
- Hub Bore Diameter: 72.6mm
- Lug Seat: 60° Conical
- All-Season Approved: Yes
| Wheel Size | Offset (mm) | Weight (lbs./kg) | Load Rating (lbs./kg) |
|---|---|---|---|
| 17"×8.0" | +45 | 16.6/7.5 | 1521/690 |
| 17"×8.0" | +35 | 17.4/7.9 | 1521/690 |
| 18"×8.0" | +40 | 18.8/8.5 | 1521/690 |
| 18"×8.0" | +30 | 19.4/8.8 | 1521/690 |
| 18"×9.0" | +40 | 19.0/8.6 | 1521/690 |
| 18"×9.0" | +30 | 19.2/8.7 | 1521/690 |
| 19"×8.5" | +45 | 20.8/9.4 | 1521/690 |
| 19"×8.5" | +35 | 21.4/9.7 | 1521/690 |
| 19"×9.5" | +45 | 20.0/9.1 | 1521/690 |
| 19"×9.5" | +35 | 20.4/9.3 | 1521/690 |
| 20"×8.5" | +45 | 22.8/10.3 | 1797/815 |
| 20"×8.5" | +35 | 23.8/10.8 | 1797/815 |
| 20"×9.5" | +45 | 23.4/10.6 | 1797/815 |
| 20"×9.5" | +35 | 24.2/11.0 | 1797/815 |
| Wheel Size, Offset | 17"×8.0", +45mm | 17"×8.0", +35mm | 18"×8.0", +40mm | 18"×8.0", +30mm | 18"×9.0", +40mm | 18"×9.0", +30mm |
|---|---|---|---|---|---|---|
| CX-3 | 2016-2022⚠️ New tires required High-Type Center Cap required |
2016-2022⚠️ New tires required |
2016-2022⚠️ New tires required High-Type Center Cap required |
❌ | ❌ | ❌ |
| CX-30 | 2020-2025⚠️ New tires required High-Type Center Cap required |
2020-2025⚠️ New tires required |
2020-2025⚠️ New tires required High-Type Center Cap required |
❌ | ❌ | ❌ |
| CX-5 | 2013-2025⚠️ High-Type Center Cap required |
2013-2025✔️ | 2013-2025⚠️ New tires required High-Type Center Cap required |
2013-2025✔️ | 2013-2025⚠️ New tires required High-Type Center Cap required |
❌ |
| CX-50 | 2023-2025✔️ | 2023-2025✔️ | 2023-2025✔️ | 2023-2025✔️ | 2023-2025⚠️ New tires required |
2023-2025⚠️ Aggressive Fitment New tires required |
| CX-7 | 2007-2012⚠️ New tires required |
2007-2012⚠️ New tires required |
2007-2012✔️ | 2007-2012⚠️ New tires recommended |
❌ | 2007-2012⚠️ Aggressive Fitment New tires required |
| CX-9 | ❌ | ❌ | ❌ | ❌ | ❌ | ❌ |
| Mazda3 | 2014-2025⚠️ New tires required High-Type Center Cap required |
2014-2025⚠️ New tires required Aggressive Fitment |
2014-2025⚠️ Aggressive Fitment High-Type Center Cap required |
❌ | ❌ | ❌ |
| Mazda6 | 2009-2021⚠️ High-Type Center Cap required |
2009-2021✔️ | 2009-2021⚠️ New tires required High-Type Center Cap required |
❌ | 2014-2017⚠️ New tires required High-Type Center Cap required |
❌ |
| RX-8 | 2004-2011✔️ | 2004-2011✔️ | 2004-2011✔️ | 2004-2011✔️ | 2004-2011⚠️ New tires required High-Type Center Cap required |
2004-2011*⚠️ New tires required High-Type Center Cap required |
| Wheel Size, Offset | 19"×8.5", +45mm | 19"×8.5", +35mm | 19"×9.5", +45mm | 19"×9.5", +35mm | 20"×8.5", +45mm | 20"×8.5", +35mm | 20"×9.5", +35mm |
|---|---|---|---|---|---|---|---|
| CX-3 | 2016-2022⚠️ New tires required |
❌ | ❌ | ❌ | ❌ | ❌ | ❌ |
| CX-30 | 2020-2025⚠️ New tires required |
❌ | ❌ | ❌ | 2020-2025⚠️ New tires required |
❌ | ❌ |
| CX-5 | 2013-2025⚠️ New tires required |
2013-2025⚠️ New tires required |
2013-2025⚠️ New tires recommended and High-Type Center Cap |
2013-2025⚠️ New tires required |
2013-2025⚠️ Aggressive Fitment New tires required |
2013-2025⚠️ New tires required |
2013-2025⚠️ Aggressive Fitment New tires required |
| CX-50 | 2023-2025⚠️ New tires required |
2023-2025⚠️ Aggressive Fitment New tires required |
❌ | 2023-2025⚠️ Aggressive Fitment New tires required |
2023-2025✔️ | 2023-2025✔️ | 2023-2025⚠️ Aggressive Fitment New tires required |
| CX-7 | 2007-2012✔️ | 2007-2012⚠️ New tires recommended |
❌ | 2007-2012⚠️ Aggressive Fitment New tires required |
2007-2012⚠️ New tires required |
2007-2012⚠️ New tires required |
2007-2012⚠️ Aggressive Fitment New tires required |
| CX-9 | ❌ | ❌ | ❌ | ❌ | 2007-2023✔️ | 2007-2023⚠️ New tires recommended |
2016-2023⚠️ New tires required |
| Mazda6 | 2009-2021⚠️ New tires recommended |
2014-2021⚠️ New tires recommended |
2014-2021⚠️ Aggressive Fitment New tires required |
2014-2021⚠️ Aggressive Fitment New tires required and High-Type Center Cap required |
2009-2021⚠️ New tires required |
2014-2021⚠️ Aggressive Fitment New tires required |
2014-2021⚠️ Aggressive Fitment New tires required |
| RX-8 | 2004-2011✔️ | 2004-2011✔️ | 2004-2011⚠️ New tires required High-Type Center Cap required |
2004-2011*⚠️ New tires required High-Type Center Cap required |
2004-2011⚠️ New tires required |
2004-2011⚠️ New tires required |
2004-2011*⚠️ New tires required High-Type Center Cap required |
- ✔️: Applicable/approved fitment with OE tire size
- ⚠️: Aggressive fitment and/or requires Different Tire Size from factory (Contact us for more specific details)
- ❌: Not applicable
- *Specific to RX-8 models, Staggered Rear Width setup available:
- Front: 18"×8.0",+40mm | Rear:18"×9.0", +40mm
- Front: 18"×8.0",+40mm | Rear:18"×9.0", +30mm
- Front: 18"×8.0",+30mm | Rear:18"×9.0", +40mm
- Front: 18"×8.0",+30mm | Rear:18"×9.0", +30mm
- Front: 19"×8.5",+45mm | Rear:19"×9.5", +45mm
- Front: 19"×8.5",+45mm | Rear:19"×9.5", +35mm
- Front: 19"×8.5",+35mm | Rear:19"×9.5", +45mm
- Front: 19"×8.5",+35mm | Rear:19"×9.5", +35mm
- Front: 20"×8.5",+45mm | Rear:20"×9.5", +35mm
- Front: 20"×8.5",+35mm | Rear:20"×9.5", +35mm
All listed sizes for each vehicle are wheel manufacturer-recommended fitments based on factory vehicle suspension components, and no vehicle modifications should be necessary.
Should your vehicle have any modifications, then we can no longer guarantee fitment to your vehicle. If your Mazda is not listed, then this wheel does not have an appropriate size available for your vehicle.
Special Notes
- Wheel includes bespoke center cap
Not compatible with Mazda factory center caps - Does not include tire valves or Tire Pressure Monitoring System Sensors
- Compatible with Mazda TPMS Sensors
- Available Chrome Tire Valve Stems
- Please ensure you select the correct size of wheels for your vehicle
- If you choose to upsize or downsize, the corresponding tire size must also be changed
- If you are unsure of your sizing, please contact us and we'll be more than happy to help!
- Installation Option Available: Please contact us for further details
- Please review our Shipping Policies prior to purchase
- Be sure to also check out our collection of All Season Tires and Winter Tires to get you set for the roads!
About Fast Wheels
Fast Wheels is a proudly Canadian alloy wheel brand dedicated to covering a wide range of wheel styles and fitments for all types of passenger vehicles. Their team has over 30 years experience in wheels, and our products are a testament to our enthusiasm and wealth of industry knowledge.
Fast Wheels is committed to overseeing each step of a wheel’s existence. From the moment it’s conceived on the computer screen to its birth in the casting machine, each step of the manufacturing process is closely monitored. The wheel is seen through a series of certification tests right down to the finishing and packaging, making sure your wheels are constructed with the highest quality control standards in the industry.
